K-Swap Shifter Cables
These cables are built like all other Hybrid Racing shifter cables; however, they are designed to combine different transmissions and shifters. These are typically used in engine-swapped cars, specifically ones using the Honda K-Series gearbox.
92-00 Honda Civic & 94-01 Acura Integra K-Swap - Using the K20A, K20A2, K20A3 and K20Z1 gearbox. These cables must use the DC5 style shifter OR the Hybrid Racing A2 bolt in shifter. The cables will exit underneath the chassis, and the cables should route above the subframe.
SKU: HYB-SCA-01-07 CLICK TO LEARN MORE
92-00 Honda Civic & 94-01 Acura Integra K-Swap - Using the K20Z3 transmission and the Hybrid Racing Z3 bolt in shifter. The cables will exit underneath the chassis, the cables should route above the subframe.
SKU: HYB-SCA-01-34 CLICK TO LEARN MORE
92-00 Honda Civic & 94-01 Acura Integra K-Swap - Using the K24A2, K24A4, K24A8 transmission and the Hybrid Racing Z3 bolt in shifter. The cables will exit underneath the chassis, and the cables should route above the subframe.
SKU: HYB-SCA-01-36 CLICK TO LEARN MORE
92-00 Honda Civic & 94-01 Acura Integra K-Swap - Using the K20Z3 transmission and the Acura TSX or Hybrid Racing TSX short shifter. This requires the shifter to be mounted inside the car on top of an adapter base. The cables will exit through an existing (or created) hole in the firewall.
SKU: HYB-SCA-01-33 CLICK TO LEARN MORE
92-00 Honda Civic & 94-01 Acura Integra K-Swap - Using the K24Z, K20Z4 or K20A FD2 Type-R transmission and the Hybrid Racing Z3 bolt in shifter. The cables will exit beneath the chassis and should route above the subframe.
SKU: HYB-SCA-01-09 CLICK TO LEARN MORE
92-00 Honda Civic & 94-01 Acura Integra K-Swap - Using the K24Z, K20Z4 or K20A FD2 Type-R transmission and the Acura TSX or Hybrid Racing TSX short shifter. This requires the shifter to be mounted inside the car on top of an adapter base. The cables will exit through an existing (or created) hole in the firewall.
SKU: HYB-SCA-01-35 CLICK TO LEARN MORE
02-08 Honda Fit / Jazz & 09-14 Honda Fit / Jazz K-Swap - Using the K20Z3 transmission. These cables use the OE Honda Fit / Jazz shifter.
SKU: HYB-SCA-01-44 CLICK TO LEARN MORE
07-14 Honda Fit / Jazz K-Swap - Using the K24Z, K20Z4 or K20A FD2 Type R transmission and the OE or Hybrid Racing Fit shifter.
SKU: HYB-SCA-01-42 CLICK TO LEARN MORE
90-05 Acura NSX K-Swap - Using the K20A, K20A2, K20A3 or K20Z1 transmission. This requires the use of the Hybrid Racing short shifter (installed backward, pointing towards the gearbox) and the Hybrid Racing RWD shifter cable bracket. The cables will exit the front of the transmission and snake into the cabin. Because the shifter is now pointing towards the transmission, the cables will install straight onto the shifter. There will be shifter mount modifications needed in order for the shifter to work with the factory E-brake bracket.
SKU: HYB-SCA-01-96 CLICK TO LEARN MORE
92-00 Honda Civic & 94-01 Acura Integra B-Series AWD - using the Honda B-Series All Wheel Drive transmission. These shifter cables require the use of the Hybrid Racing TSX style short shifter, top chassis mounting plate and the factory B-Series AWD shifter cable bracket. The cables will exit the shifter inside the chassis and must go through an existing or created hole in the firewall. They mount directly to the factory B-Series AWD shifter cable bracket.
SKU: HYB-SCA-01-04 CLICK TO LEARN MORE
